My Personal 13.3″ ThinkPad History

June 11, 2021 Ed Tittel Leave a comment

As I wrote in yesterday’s blog post X390 Yoga Replaces X220 Tablet, my trusty old ThinkPad X220 Tablet is aging out of useful Windows test machine status. This got me to thinking about my personal 13.3″ ThinkPad history. In fact, all of those PCs are still in the room here with me and I’d like to run through them in today’s disquisition. Let’s tackle the series in chronological order.

My Personal 13.3″ ThinkPad History Begins

It all started in 2012, when Que (Part of Pearson Publishing) asked me to help revise Windows 7 in Depth for the upcoming release of Windows 8. Its beta release occurred in February, and I started looking for a pair of suitable test PCs at that time. Because touch was integral to Windows 8, but still rare and expensive, one of those two units HAD to include a touchscreen. That’s what led me to the ThinkPad X220 Tablet (and a ThinkPad T420 laptop) both with i7-2650M CPUs, 8 GB RAM, and (if memory serves) 500MB 2.5″ spinning disk drives. Read more about the ThinkPad X Series at Wikipedia.

Changes and Upgrades Follow

Over the next few years, I made many changes to those two laptops. SSDs emerged and I endowed each of them with Plextor mSATA 256 drives. This let me take advantage of their empty M.2 slots, which were designed to handle either cellular wireless access or storage. I also upgraded the HDDs to OCZ SATA-III SSDs, doubled up RAM on both machines to 16 GB, and purchased a PCIe card with 2 USB 3 ports to include higher-speed USB access on those PCs (both include only USB 2 ports built-in).

Over the years, these machines served me faithfully and well. I took them on the road for many legal and consulting jobs, not to mention family trips. Last year, the T420 proved increasingly difficult to upgrade to production Windows 10 versions. But the X220 Tablet kept chugging along until about 4 months ago, when a new Intel Management Engine upgrade failed, and left that firmware in a perpetual error state. Since then, it too, has proved increasingly difficult to upgrade to the latest Dev Channel Insider updates and upgrades. That said, the machine was designed in 2011 and purchased in 2012, so I would have to say it’s had a long and productive go here at Chez Tittel.

Phase 2: X380 Yoga Comes Aboard (2018)

In 2018, I actually acquired 2 X380 Yogas, both more or less identically configured. Each includes an i7-8650U Intel 7th generation (codename Kaby Lake) CPU, 16 GB DDR4 soldered RAM, and a 1 TB NVMe OEM SSD. (One has a slower Toshiba, and the other a faster Samsung model.) I use one for the production version of Windows 10 (currently 20H2 awaiting the 21H1 enablement package offer from WU). The other one runs Windows 10 Dev Channel Insider Preview release (currently at Build 21390.1010).

The X380 has proved an excellent bring-along family/entertainment PC, when I’ve also carried a “work machine” on family trips and vacations. It’s got the right combination of size, display, computing capabilities, and battery life to make a great media platform.

Phase 3: X390 Yoga Joins the Party (2019)

As my wife’s ancient Mini-ITX PC (Ivy Bridge i7) started showing signs of age, I decided to buy an X-series ThinkPad for her as a main machine, hooked up to an external monitor, mouse and keyboard using a Belkin USB 3.1/Thunderbolt 3 dock. That didn’t pan out, so I got her a Dell Optiplex 7080 Micro in 2020 instead. I’m using the X390 as a test machine for Insider Preview releases, and have also taken it on the road. It’s pretty much identical to the two X380s except for some minor port differences. (The X390 has two USB-C ports one of which is Thunderbolt 3 capable; the X380s have more USB-A ports and fewer USB-C).

Phase 4: ThinkPad X1 Yoga Gen 6 Gets a Look-See (2021)

Because of my long and productive history with this particular ThinkPad series, I contacted Lenovo to see if the might send me the latest 11th Generation (Tiger Lake) version of this PC. They did: it arrived here yesterday. Known as X1 Yoga Gen 6, the unit has an i7-1185G7 CPU, 16 GB of LPDDR4x 4266MHz RAM, and a 500GB Hynix SSD (an OEM model I’ve never come across before). It’s got enough interesting bells and whistles that I’m looking forward to writing up a first look on this nice little laptop. Also, this machine is my first exposure to Lenovo in some color other than black (it’s a mat and muted steel grey all over as you can see in the photo).

It’s too early to tell much about this PC. So far, I’ve turned it on, hooked it up to Wi-Fi, set up my Microsoft account, and installed a few apps (mostly for testing and benchmarking). You can see its publicity photo, however, as the lead-in graphic for this story. I’m planning to write a first look piece about it next week. Stay tuned!

Hardware Reviews, Recent Activity, WED Blog, Windows 10, Windows Update

X390 Yoga Replaces X220 Tablet

June 10, 2021 Ed Tittel 1 Comment

With the 2012 vintage Lenovo X220 Tablet going into a well-earned retirement, I need a replacement Dev Channel test machine. I’ve decided to call upon my 2019 vintage Lenovo X390 Yoga to fill that role. As the X390 Yoga replaces X220 Tablet, I’m sure I’ll be learning a lot more about this machine, even though it’s been around for 16 months or so.

More About X390 Yoga Replaces X220 Tablet

Originally, I purchased this laptop to replace my wife’s aging Ivy Bridge mini-ITX PC. I ended up going for a Dell Optiplex 7080 Micro instead. Since I bought the machine in December 2019, I’ve been using it to test the current GA version of Windows 10. Now, it’ll switch over to following the latest bleeding-edge Dev Channel releases.

Here’s how that PC is equipped:

8th Generation (Whiskey Lake) i7-8565U CPU
16 GB RAM (2×8 GB, soldered, DDR4 2400 MHz)
Intel UHD Graphics 620
SSDPEKKF512G8L Intel 1TB NVMe SSD
Intel Wireless-AC 9560 160Mhz Wi-Fi adapter
13.3″ FHD (1920×1080) touchscreen
Fingerprint reader, Windows Hello camera
2xUSB 3.1 Gen 1; 1xUSB-C; 1xUSB-C/Thunderbolt 3
MicroSD card slot
ThinkPad Pen Pro stylus included
Dimensions: 12.2″ x 8.6″ x 0.63″ / 310.4 x 219 x 15.95 (mm)
Weight: 2.85 lbs (1.29 kg)

Lenovo’s port map graphic that follows shows where everything is, on the unit’s right and left sides. It’s been a treat to work with and use.

X390 Yoga Replaces X220 Tablet.portmap (click image for full-sized view).

Backup and Restore

Any test machine has to have backup/restore capability. That’s because there’s always the chance that updates, upgrades, or fiddling about will cause trouble. That’s what beta testing is about. I’m also prone to occasional “what-ifs” that have landed my PCs in trouble. Thus, it pays to be prepared.

I’ve got a speedy SATA-III SSD (Sabrent enclosure, Samsung EVO 500 nominal/465 GB actual) plugged into the USB-A port for backup. It takes about 6.5 minutes to do a complete image backup of the boot/system (and only current) drive. I’ll need to pop for a microSD card for this machine, now that’s it’s moving into a more active test role. I’ve also got a Macrium Reflect bootable Rescue Media USB Flash device ready to run restore as and when I need it.

How I Work with Test Machines

I don’t work directly on my test PCs, unless there’s some activity or utility that won’t work remotely. Frankly, I use RDP from my primary desktop for most interactions. That’s because I can do everything from my comfortable desk chair working on 2 Dell 2717 monitors. Almost everything works well that way. And if I do need to access the X390, I need only rotate my office chair to the left to access the unit. It’s situated atop a rolling file cabinet right next to my desktop case.

As time goes by, I’ll be writing about this nifty little laptop more and more in dealing with Windows 10 Dev Channel releases and related topics. Keep an eye out, and you’ll soon see evidence to support this prediction. Cheers!

Benchmarking, Hardware Reviews, Recent Activity, WED Blog, Windows 10

Living with the Lenovo ThinkPad X12

June 4, 2021 Ed Tittel Leave a comment

It’s been nearly a month since the brand-new ThinkPad X12 showed up at my front door. Since then, I’ve used it for a variety of everyday computing tasks, including writing stories, conducting research, tuning and tweaking, and more. As I’ve gotten to know it better, I’ve come to like it better as well. It’s not exactly perfect, but it’s not bad, either. In fact, living with the Lenovo ThinkPad X12 has been a mostly positive experience.

It’s Good, Living with the Lenovo ThinkPad X12

Here’s what this machine brings to its users:

CPU: 11th Gen i7-1180G7 (formerly Tiger Lake; 4 cores/8 threads; 12 MB Intel Smart Cache; max frequency: 4.6 GHz)
RAM: 16 GB (neither Speccy nor CPU-Z will tell me anything about the soldered-in RAM in this unit: interesting! The product page shows it as LPDDR4X 4266MHz.)
Graphics: Intel Iris Xe Graphics
Display: 12.3″ FHD 1920×1280 anti-reflective touchscreen 400 nits: bright and readable enough for me
SSD: Western Digital SN530 SDBPMPZ-1T00-1001 NVMe PCIe Gen3 x4 interface 1TB capacity (nominal: 953 actual)
Wi-Fi: Intel Wi-Fi 6 AX-201 160MHz adapter
Keyboard deck with fingerprint reader, pen/stylus included in purchase

Right now, the purchase price for an identically configured unit at the Lenovo website is US$1,570.00 (Memorial Day sale price). There is one kicker though: the site says “ships in 4+ months…delay due to COVID-19 global pandemic.” Ouch!

What I Like About the ThinkPad X12

This four-core/eight-thread mobile CPU is surprisingly fast and capable. Hooked up to a Thunderbolt 3 dock, I get access to added storage, wired GbE (if I want it), and more than enough wattage to charge its battery nicely. The Wi-Fi 6 adapter is amazingly peppy: I just got 640-plus Mbps from Ookla Speedtest to my nominal GbE Spectrum connection. It’s almost as fast as GbE, and sometimes I don’t even notice it’s connected wirelessly.

Battery life is great, too. I routinely got 10 hours or better when using the device untethered. Such use involved mostly reading Kindle eBooks, light-duty e-mail checks and web surfing, and watching an occasional video. It’s much better than my old (2014 vintage) Surface Pro 3, on which I’m lucky to get 4 hours of battery life.

It’s especially cool that Lenovo includes the keyboard cover (with fingerprint reader) and a pen/stylus as part of the purchase package. MS still charges separately for those, to the tune of US$150-200, depending on deals and options.

What Don’t I Like About the ThinkPad X12?

Not a whole lot actually. That said, I was surprised at the relatively slower speeds from its Western Digital SSD. Check out the CrystalDiskMark results from the X12 (left) vs. my 2018 vintage X1 Extreme, with a Samsung OEM 1 TB SSD. Makes me wish Lenovo had picked a bit more expensive SSD for the X12 .

X12 CrystalDiskMark 8 left, X1 Extreme right.
[Click image for full-sized view.]

Other negatives are mostly minor. There’s no microSD or SD card slot for flash media. The unit sports 2 USB-C/Thunderbolt 4 ports, but no USB-A (or other ports, except an RCA mini-jack for audio). The built-in speakers are fairly flat and lacking in power and the front and rear cameras relatively low in resolution and visual fidelity. For me, none of this is a big issue, nor a deal-breaker.

I wanted something more affordable, a bit faster, and with better battery life to replace my aging Surface Pro 3. For my needs, especially for reading eBooks in bed, the ThinkPad X12 is a winner. It’s as close to an iPad with real PC capabilities as I’ve ever come. IMO, it’s worth taking seriously. If it fits your needs like it does mine, it’s worth buying, too.

Hardware Reviews, Recent Activity, WED Blog, Windows 10

First Look: Lenovo X12 Tablet PC

May 12, 2021 Ed Tittel Leave a comment

I’ve owned a Surface Pro 3 since 2014. Before that I owned a Fujitsu Q704. Both were small, powerful, somewhat loaded i7 tablets. I also had a Dell Venue Pro 11 with an i5 CPU. I liked all of those machines. Indeed, I appreciate a moderately powerful tablet PC that’s compact and can handle office/productivity work. That’s why I requested “something similar” from Lenovo. They sent me their latest detachable 11th Gen (Tiger Lake) ThinkPad X12 last week. This is my first look: Lenovo X12 Tablet PC introduction and overview.

Speccy lists basic componentry: 4-core 11th-gen i7, 16 GB RAM, Iris Xe graphics, 1 TB WD SSD, Intel AX201 Wi-Fi.
[Click image for full-sized view.]

Taking a First Look: Lenovo X12 Tablet PC

Lenovo also sent me a full-sized wired keyboard and a ThinkPad Thunderbolt 3 Dock Gen 2 (PN: 40AN0135US). I wouldn’t recommend attempting serious use of this device without a USB3 or Thunderbolt 3/4 dock, because it needs backup storage at a minimum. The ability to add one or two monitors via HDMI or DisplayPort is nice, as is wired GbE and a bunch of USB3 ports (4 on the back, 1 on the front). The unit I received MSRP is over US$2,500 but you won’t pay Lenovo more than US$1,700 to actually take it home (not including wired keyboard and Thunderbolt dock).

In the connectivity vein, the X12 features a Thunderbolt 4 controller for its USB-C ports. AFAIK, this is the first time I’ve worked with a PC that has Thunderbolt 4 support, rather than the preceding version. It picked up my Belkin dock immediately (though it’s a Tbolt 3 version device). It just happened to be sitting on the same desk, and immediately brought up the Seagate 5TB and a 16 GB Mushkin USB3 UFD, as you can see in the Speccy screencap above.

My first time to see Thunderbolt 4 come up in the eponymous control center app.

Basics Stats, Look and Feel

The tablet is thin and light (1.67 lbs sans keyboard; 2.4 lbs with). Dimensions are petite at 11.15 x 8.01 x 0.34″ (sans keyboard) or 0.57″ (with keyboard) (in mm that’s 283 x 204 x 8.6 or 14.5). Nevertheless, it feels pretty sturdy in the hand and on the lap (though I don’t much care for the lapabilty of this kind of PC ). If I’m not at a desk or table, I prefer to use the tablet by itself sans keyboard.

It’s got a full HD panel (1920×1280 pixels) that’s rated at around 400 nits of brightness. So far, I’ve found it fine for reading, surfing and handling email (but I really haven’t put it through too many of its paces just yet). I’m not quite familiar enough to rate its battery life yet, either. That said, it’s never flagged while I’ve used it, though I’ve yet to use it for longer than 4 hours.

More to Come … Soon

That’s it for today’s first look. I am impressed enough with the X12 to be considering a purchase of my own such unit. I will take more time to play, measure, and experiment. Then, I’ll know better if my desire to own this beast is merely a passing case of techno-lust, or a genuine desire to own another tablet to replace my aging Surface Pro 3. Stay tuned!

Hardware Reviews, Networking, Recent Activity, Services, WED Blog, Windows OS Musings

Pondering Amazon Fire HD vs. iPad

April 28, 2021 Ed Tittel Leave a comment

Today’s disquisition is a bit off the beaten track and brings Windows 10 to bear only tangentially. My family is in the market for another tablet, primarily for reading and media consumption. I’ve already owned an iPad 2 (now retired) and currently own an iPad Air 2 (2014 vintage). You’d think I’d buy another iPad, right? But the model I want (iPad Air, 256 GB, cellular) costs a whopping US$879 at the Apple Store right now. And then, there’s a new generation of Fire HD tablets about to arrive, at less than half that cost. By the time I add in a cover and keyboard, it’s more like a 2.5:1 cost ratio. Frankly, that’s what has me pondering Amazon Fire HD vs. iPad.

Price Provokes Pondering Amazon Fire HD vs. iPad

On the plus side, the iPad offers more power, lighter weight, and higher screen readability. On the minus side, it ends up costing $700 more for more or less the same capability, most of the time. At 12 hours versus 10 hours of battery life, the Amazon Fire HD comes out ahead on untethered operation, too. Then too, the Fire HD Plus Pack costs under US$300. The device even accommodates a MicroSD card for added storage capability (which the iPad does not, though you can attach storage through its input port, using a special US$13 to 20 adapter).

What’s fascinating to me, though, is the front-and-center add-in on the Fire HD of a Microsoft 365 subscription. Though it means you can use the unit for web-based Office right away, I’m also convinced it will be usable as a Cloud PC client (as will the iPad also, no doubt) when that comes out later this year. Thus, either platform will serve as a “thin client” for my Windows 10 stuff sooner or later.

To me that raises the very real question of why I should spend 333% more to get an iPad? Shoot, it looks like Fire HD can do most of what I need for substantially less. For a lot of people, I’m thinking that’s exactly what Amazon wants. I may just try it, and see what happens!

Benchmarking, Hardware Reviews, Networking, Recent Activity, USB devices, WED Blog, Windows 10

Thunderbolt 4 Is Getting Underway

April 14, 2021 Ed Tittel Leave a comment

OK, then: first things first. Thunderbolt is a joint technology effort from Intel and Apple. The first iteration appeared in 2011, and version 4 (aka Thunderbolt 4) is just showing up in the marketplace. Intel’s 11th gen processors and supporting motherboards are the first to provide native Thunderbolt 4. And of course, add-on PCIe cards for Thunderbolt 4 are also starting to trickle out (see this ASUS item, for example). Hence the assertion that heads this story: Thunderbolt 4 is getting underway.

I’ve had recent experience to show me that the speed advantages it can confer are measurable and tangible. At the same time, I’ve learned that the right cables can — and do — make huge differences.

What Thunderbolt 4 Is Getting Underway Really Means

The following table sums up the differences among Thunderbolt 3 and 4, and USB 3 and 4 versions. Basically, it offers more and faster capabilities, but is limited to special, certified cables no more than 2M in length. It can also handle either 2 4K displays or 1 8K display, and works with the latest PCIe 32Gbps lanes. It is, in fact, a pretty strong argument for all-around hardware upgrades (mobo and ports, cables, and peripherals) all by itself. Check the table for details, please.

.	Thunderbolt 4	Thunderbolt 3	USB4	USB 3/DP
1 universal port	✓	✓
40Gb/s cables up to 2 meters	✓
Accessories with up to 4 TB ports	✓
Min PC speed requirement	40Gb/s	40Gb/s	20Gb/s (40Gb/s is optional)	10Gb/s
MinPC video requirement	2 x 4K displays or 1. x 8K display	1 x 4K display	1` display (no min resolution)	1 display (no min resolution)
Min PC data requirements	PCIe 32Gb/s USB.3.2 10Gb/s	PCIe 16Gb/s USB 3.2 10Gb/s	USB.3.2 10Gb/s	USB 3.2 5Gb/s
PC charging port required	At least one
PC wake from sleep w/TB dock connected	Required
MinPC port power for accessories	15W	15W	7.5W	4.5W
Thunderbolt networking	✓	✓
Mandatory certification for PCs and accessories	✓	✓
Intel VT-d based DMA protection required	✓
USB4 specification	Compliant	Compatible	Compliant	Compatible
Source: Table from 11/20/2020 Liliputing story about Thunderbolt and USB versions.

What I Plan To Do About Thunderbolt 4

I’ve got a new PC build in my relatively near future (as soon as finances allow). I’ll be making sure to pick motherboard and CPU with Thunderbolt 4 support. I’m looking around right now and while some cases do offer USB-C support, none of them have caught up to Thunderbolt 4 capability just yet. I may end up waiting for that to occur, and go ahead and recycle the trusty old Antec 902 case I recently reclaimed from my sister. This may take some further thought and research. Stay tuned!

Benchmarking, Hardware Reviews, WED Blog, Windows 10

Tiny 1TB SSD Toshiba Technology Triumph

April 2, 2021 Ed Tittel Leave a comment

Yeah, I know. They’re not called Toshiba anymore. it’s now Kioxia, but Toshiba’s the name on the stick-on label. It’s stuck on a teeny tiny 2230 M.2 SSD I just installed in my Dell Optiplex 7080 Micro SFF PC. And in this case 2230 means it’s a package that measures 22 mm wide and 30 mm tall. It’s not much bigger than an SD card. It’s also reasonably fast and amazingly compact. That’s why I call it a tiny 1TB SSD Toshiba technology triumph.

What Makes for a Tiny 1TB SSD Toshiba Technology Triumph?

It just blows my mind that one can buy a 1TB SSD that’s so darn small. It uses the PCIe Gen3 x4 NVMe 1.3b interface, so it also runs surprisingly fast. The specs page says it runs up to 2.3 GB/sec. I observed speeds of just over 2.0 GB/sec on CrystalDiskMark in the Dell 7080 Micro.

I confess I had to go to eBay to buy this device. In fact, they’re not currently for sale directly to end-users through conventional online outlets. That said, I paid under US$200 for the unit, which I consider an amazing deal given how much demand there is right now for such compact, capacious storage devices.

Seems Rock-Solid, But We’ll See

Having just received it in yesterday’s mail and installed it today, I can’t claim much experience with this unit just yet. Recalling issues with the Sabrent 2242 unit I tried out earlier, I’m reserving judgement. But I am stunned. It’s so small!

I’ve haven’t been this excited about miniaturization since I visited Madurodam in the Hague back in 1964 as a Boy Scout. There was a lot more to see there and then, but this little SSD definitely rocks the storage in today’s world. Stay tuned for more info, stats, and such as I get to know this little powerhouse better with time.

Interestingly, Dell doesn’t provide a hold-down screwport on the 7080 motherboard. I had to tape the drive down with some electrical tape to hold it in position. I have a nut I can superglue to the mobo at some future point instead. I’m still pondering that, as I get to know this device better. Stay tuned for more deets next week!

Hardware Reviews, Recent Activity, Tips, Tricks and Tweaks, WED Blog, Windows 10

A Tale of Two USB Ports

March 18, 2021 Ed Tittel Leave a comment

I’ve been troubleshooting a vexing M.2 2242 NVMe drive this week. If you look back over my recent writings here at edtittel.com, you’ll see this adventure has led me to some interesting places. Yesterday, it led me to recognize that not all USB-C ports are the same. I found myself confronting the profound difference that current-gen Thunderbolt support can make. Thus indeed, a tale of two USB ports follows.

Telling the Tale of Two USB Ports

On the one hand: a 2019-vintage Lenovo X390 Yoga. Its fastest USB port is described in its tech specs as “USB 3.1 Gen 2 Type-C / Intel Thunderbolt 3.” On the other hand: a 2021-vintage Lenovo X1 Nano. Its fastest USB port is described in its tech specs as “USB 4 Thunderbolt 4.” I must confess, I was curious about what differences might manifest between these two technology generations.

It made a significant difference. Thus the story’s lead-in graphic shows. CrystalDiskMark output from the Nano is on the left, the X390 on the right. It shows the speed-up varies somewhat. It is better than 2:1 on the big-transfer items (upper 2). But the more important random 4K reads/writes fill the bottom two rows. There, we see 17-18% (read-write) for random with queue depth=1. That jumps to 42-50% with queue depth=32.

In practice, I believe it’s what allows the X1 Nano with an i5 processor to work much like my older i7-6700 on my desktop PC. It also makes the X1 Nano faster than the X390, despite an i7 on that older machine. I/O is indeed a powerful performance factor.

Is USB 4 Thunderbolt 4 Worth Buying?

If you’re in the market for a new PC or laptop, you will get a performance boost from using the newer USB technology. If the ability to complete backups (and other big file transfers) twice as fast is worth something to you, factor that into the price differential. If better overall I/O performance of at least 18% in accessing peripheral storage has value, ditto.

Only you can decide if it’s worth the price differential. For me, the answer is “Heck yeah!” I’m not sure that means I’ll buy an X1 Nano. But I am sure it means my next laptop will have USB 4 Thunderbolt 4 ports.

Hardware Reviews, Recent Activity, Troubleshooting, WED Blog, Windows 10

Strange Sabrent Rocket Adventures

March 15, 2021 Ed Tittel Leave a comment

Last Friday, I blogged about swapping out my review unit Lenovo Thinkpad X1 Nano SSD. I purchased a US$150 Sabrent Rocket Nano (Model SB-1342 1 TB). It replaced a Samsung OEM 512 GB SSD (NVMe PCIe 3.0 x4). Check the Friday post for details on performance, installation and so forth. Today, I’m writing about the strange Sabrent Rocket adventures I’ve had since taking that device out of the laptop. Frankly, it’s a continuing and wild ride.

Strange Sabrent Rocket Adventures: Drive MIA

First, I used Macrium Reflect to clone the original Samsung drive. Then, I made the swap, ran some tests and replaced the Sabrent with the original SSD. Things got intersting after I plugged the drive back into the Sabrent NVMe drive enclosure (EC-NVME). The drive was MIA: it showed up as 0 bytes in size and generated a “fatal device error” if I tried to access it. Ouch! I immediately reached out to vendor tech support.

Sabrent Tech Support quickly coughed up a link to a terrific tool, though. The name of the tool is lowvel.exe, and it performs a complete low-level format of the drive, zero-filling all locations as it goes. That turned out to be just what I needed and put the Rocket Nano back into shape where DiskMgmt.msc could manipulate it once again.

Then, I initialized the drive as GPT, and set it up as one large NTFS volume. For the next 12-14 hours, I was convinced this was a final fix. But my troubles are not yet over, it seems.

More Strange Rocket Adventures

The next morning, having left the device plugged in overnight, I sat down at my desk to see it blinking continuously. When I tried to access the device, it was inaccessible. It’s not throwing hardware errors to Reliability Monitor, but I have to unplug the device and plug it back in, to restore it to working order. Something is still weird. Temps seem normal and the Sabrent Rocket Control Panel utility (shown in this story’s lead-in graphic) gives the device a clean bill of health.

I’ve got an intermittent failure of some kind. I need more data to figure this one out. I’m leaving the Control Panel running on the test laptop where the Rocket Nano is plugged in. We’ll see if I can suss this one out further. It’s not inconceivable I’ll be going back to Sabrent Tech Support and asking for a replacement — but only if I can prove and show something definite and tangible. Sigh.

Info Added March 25: All Is Quiet

Who’d have thought a Sabrent NVMe enclosure and a Sabrent NVMe drive might be ill-fitted together? Apparently, that’s what ended up causing my intermittent failures. On a whim, I bought the cheapest NVMe enclosure I could find — a US$26 FIDECO USB 3.1 Gen 2 device — into which I inserted the Sabrent Nano SSD. It’s now run without issue, pause, hitch, or glitch for a week. I did not insert the device pad that normally sits between the case and the device (already present in the Sabrent enclosure). I’m inclined to blame some kind of heat buildup or connectivity issue resulting from an overly tight fit in the Sabrent enclosure, which I may have avoided in its FIDECO replacement. At any rate, it’s working fine right now. Case closed, I hope!

Hardware Reviews, Recent Activity, Troubleshooting, WED Blog, Windows 10

Swapping X1 Nano NVMe Drives

March 12, 2021 Ed Tittel Leave a comment

OK, then. I went and sprung US$150 for a Sabrent 1TB M.2 2242 NVMe drive at Amazon. It is depicted in the lead-in graphic above. The high-level sequence of events is as follows. Ordered on Wednesday, received and experimented on Thursday, reported on Friday (today). Alas, I seem to have hosed the drive and have started RMA negotiations with Sabrent. Along the way, I learned most of what’s involved in swapping X1 Nano NVMe drives.

Be Careful When Swapping X1 Nano NVMe Drives

As is almost always the case, there’s a YouTube video for that. It showed me everything I needed to do. Disassembly/reassembly were easy and straightforward. I had no mechanical difficulties. But once again, my US$7 investment in a laptop screws collection saved my butt. I mislaid one of the two NVMe holder screws (found it later during cleanup). I lost one of the 6 battery restraint screws (fell on the floor into neutral brown carpet). Both were easily replaced from the collection.

Cloning Works, But Proves Mistaken

For whatever odd reason, the Sabrent drive shows up pre-formatted. The disk layout is MBR and the primary partition is ExFAT. Both of those got in my way as I cloned the original drive to the replacement. First, I had to clean the drive, convert to GPT, then format it as a single NTFS volume. Then, I used Macrium Reflect to clone the contents of the Samsung OEM drive to the Sabrent. Along the way Reflect told me it had turned off BitLocker and that I would need to re-enable it after boot.

Replacing the Samsung with the Sabrent, I went into BIOS and turned secure boot off instead. This let the X1 Nano boot from the cloned drive just fine. I was able to run CrystalDiskMark to compare their performance. Here’s what that looks like:

Samsung OEM results left; Sabrent results right. Best improvement where it counts most!
[Click image for full-sized view.]

What do these results show? Indeed, the Sabrent is faster on all measurements, and more so on the most important random 4K reads and writes (lower two rows). It’s not a night-and-day difference, but IMO the added capacity and increased speed justify the expense involved. It’s a good upgrade for the X1 Nano at a far lower price than Lenovo charges. Also, performance is somewhat better than what their OEM stock delivers.

Here’s a summary of performance row-by-row (count 1-4 from top to bottom):
1. Read speeds increase by <1%; write speeds by >28%
2. Read speeds increase by >7%; write speeds by >36%
3. Read speeds increase by >52%; write speeds by >21%
4. Read speeds increase by >14%; write speeds by >51%

Where Did I Go Wrong?

Cloning was a mistake. I saw it in the disk layout, which showed over 400 GB of unallocated space. Better to have done a bare-metal backup using Reflect with their Rescue Media. Next time I’m in this situation, that’s what I’ll do.

Something untoward also happened when uninstalling the Sabrent drive. When I stuck it back in my M.2 Sabrent caddy (which fortunately handles 2242 as well as other common M.2 form factors), it came up with a fatal hardware error. None of my tools, including diskpart, diskmgmt.msc, MiniTool Partition Wizard, or the Sabrent utilities could restore it to working order. I suspect that removing the battery, even though the power was off on the laptop, spiked the drive with a power surge. It’s currently non-functional, so I hope my warranty covers this and I’ll get a replacement. If not, it will prove a more expensive lesson than I’d planned, but still a valuable one.
